Rupse Fuel Sender Unit Boat Fuel Tank Sending Unit Fuel Water Level Sensor Stainless Steel Fuel Sender And Fuel Gauge For Boat Car Truck Rv (4‘(100Mm))

Description

Specification Of Fuel Sending Unit: Material: Stainless Steel Length: 4’/6’/6.8’/8’/8.8’/10’/11’/12’/13′ Resolution Range: 10-21 Mm Working Voltage: 9-32Vdc Assembly: Sae Standard 5 Holes Mounting: 5Pcs M5 Screws And 2Mm Thick Gasket Signal:240-33 Ohms(240 Ohms At Empty, 33 Ohms At Full) Operational Temperature: -40°F ~ +85°F (-40°C ~ +85°C) Specification Of Fuel Level Gauge: Material: Stainless Steel+Abs Fixing Dimension: 52Mm/2′ Indicating Range: E-1/2-F Signal:240-33 Ohms Working Voltage: 9-32Vdc(12V/24V) Backlight: Red /Green /Blue /Whit /Yellow /Yellow-Green /Orange /Purple Operation Mode: Lcd Display, Stepper Motor Protection Rank: Ip67 Package Includes: 1X Fuel Sending Unit 1X Nbr Gasket 5X M5 Screws 1X Fuel Level Gauge 1X Wiring Harness 10X Butt Terminals 1X Installation Instruction
