Description
12V 24V 36V 48V 60V 72V 84Vbattery Capacity Indicator& Voltage Meter With Lcd Display Green Backlight,Waterproof Monitor Gauge Tester For 3S-26S Lithium Batteries And Lead-Acid Batteries Functions Of Battery Capacity Indicator: 1 Manually Switch Battery Percentage Voltage Power Off 2 Automatic Recycling Display Battery Capacity Voltage Per 2 Seconds (Settable) 3 10S Delay Auto Off (Settable) 4 Double Discharge Curve Selection (Settable) Specifications: Color: Black Weight: 18G Material Of Battery Capacity Indicator: Htn Pcb Dimensions: 613 * 333 * 135Mm 24 * 13 * 05In Wire Length: 30Cm 118 Voltage Range: 6-63 (V) Circuit Load Current: 5 – 6Ma Storage Temperature: -10 50 Suitable For: 3S-26S 37V Lithium Batteries Lead Acid Batteries 12V, 24V, 36V, 48V, 60V 72V 84V Setting Instruction: 1 – Connect The Cable To The Battery 2 – Hold Down The Setting Button And Plug In The Connector At The Same Time 3 – Release The Setting Button And You Should See P01 P Is The Type Of Battery: P = Lead Acid, L = Lithium, F – Lithium Iron Phosphate 4 – Press The Setting Button To Select P, L Or F5 – The Number 01 Is The Number Of Cells Or Battery Types For Lead Acid Batteries, P: 01 = One 12V Battery, 02 = Two 12V Batteries, Etc For Lithium Batteries, L: 01 = One 37V Cell, 02 = Two 37V Cells, Etc For Lithium Iron Phosphate, F: 01 = One 32V Cell, 02 = Two 32V Cells, Etc6 – Press The Setting Button To Add 1 To The Number, Function Button To Subtract 1 7 – After Setting, Eg, P01, Hold The Function Button Down To Display S – 1 8 – Press The Setting Button To Select 1 – 59 – Unplug The Connector To Save The Settings 10 – Plug The Connector Back In Package List: 1 X Battery Capacity Voltage Meter With Connecting Cable
